Extruder for the production of various food products: corn, rice sticks and balls, bread, corn flakes, pillows with stuffing, you can get the product of different shapes (stars, triangles, balls ...). In the basic version, the extruder is equipped with a microprocessor control system with touch panel operator, which significantly increases the reliability of the product and makes the process of managing the extruder clear and simple. The extruder is equipped with the necessary units (matrices half cutter, storage hopper).

Technical specifications:

Capacity up to 200 kg / h;

Power consumption: 55 kW;

Flow rate of cooling water (not more than): 300 l / h;

Power heaters, 3 pcs: 3х6 kW;

Dimensions: height of the hopper feed of 2700 mm, length 2650 mm, width 650 mm;

Weight 1500 kg.

------------------------------------

Twin-screw extruder WZ-70 is designed to produce a large range of extruded foods: soy textured, baby food, extruded starch, extruded sticks, balls, stars, pillows stuffed, bread, etc. WZ-70 has a capacity of 450 kg / h of dry mix. The extruder is easy to maintain and repair, access to all the sites and mechanisms of the free. The box of the extruder used only imported bearings. The extruder is equipped with self-cleaning screws high hardness, which excludes the presence of carcinogens and solids in the final product, and also not to allow disassembly and cleaning of the extruder zones at shutdown. The extruder is equipped with a microprocessor control system with touch panel operator and startup function, which greatly improves the reliability of the product and does protsecs control extruder simple and straightforward. The extruder is equipped with the necessary units (matrices, half cutter, storage hopper) for the chosen technology.

Technical specifications:

Capacity 450 kg / h not less;

Power consumption: 120 kW;

Flow rate of cooling water (not more than): 1000 l / h;

Dimensions: length (3 cases) to 4000 mm, width 800 mm, height 2700 mm;

Weight 3200 kg.

Extruder feed 200 kg / h

------------------------------------

Extruder is used for production of extruded floor wet granular feeds for farm and domestic animals, dogs and cats, predators, birds and fish, shrimp and shellfish. The resulting food has a high digestibility and purified from pathogenic organisms.

The raw material for extrusion can be made protein and mineral supplements.

The extruder allows to process grain and cereals of wheat, rye, corn, barley, peas, beans, lupins, soya beans, to stabilize rice bran.

Сырьем для переработки в этом экструдере может быть: зерно и крупа кукурузы, пшеницы, ржи, ячменя, гороха, рапс, соя, подсолнечник, а также возможно применять смеси разных компонентов и соевую муку. Advantage:

feed production of high quality;

the possibility of producing food with protein supplements;

may produce floating, sinking and soaring in water feed;

granules resistant to transportation;

the use of various feed waste for the preparation of raw mixtures;

decrease in feed consumption due to high digestibility prtsent.

Technical specifications:

Performance (for production of grain-based

feed components) up to kg / h 200

Steam consumption per 1 kg of feed, kg 0,03 – 0,05

Steam temperature, ° C (K) 120-140 (393 – 443)

Steam pressure supplied to the extruder MPa (kg / cm²) 0,3 – 0,6 (3–6)

Dimensions LxWxH, mm 3234х1960х3029

Rated capacity, kW 50

Parameters of electrical network 380 V, 3-phase / 50Hz

Weight, kg 1800

Extruder grain 150 kg / h

------------------------------------

This machine is designed for production of combi-feeds for farm and domestic animals and poultry with high digestibility and purification of harmful micro-organisms and substances.

The extruder allows to process grain and cereals of wheat, rye, corn, barley, amaranth, triticale and legumes (peas, lupins, etc.).

Application of this extruder allows to:

- feed production of high quality

- save up to 40% of the grain in feeding animals

- efficient use of the available raw materials

- used to control the quality of feed

- cleaned substandard raw materials from microorganisms

Principle of operation: The grain is feed from the feeding hopper with vibrating feeder in to the working body of extruder. The raw materials is fed from the hopper into the of the chute of the working body using the feeder. The raw deeding is adjusted by changing frequency of fluctuations in vibrating feeder. There is a magnet catcher of metal particles installed inside the chute.

Technical specifications:

Productivity, kg/hour up to 150

Power consumption, kW/hour 19

Length, mm 1700

Width, mm 750

Height, mm 2000

Weight, kg 700

Warranty period of wearing parts, hours 400

Warranty period, months 12

------------------------------------

Extruder grain and soy 250 kg / h

------------------------------------

This equipment is intended for production of extruded combi-feeds for cattle, pigs and poultry, and can also be used for production of full-fat soybean meal with high digestibility due to complex structural changes that take place in the grain during extrusion and purification from pathogenic organisms exposed to 20-30 atm. and temperature - 120-180 ° C

This extruder can process grain and corn cereal, wheat, barley, rye, peas, soybeans, sunflowers and others. Application of extruder improves significantly food quality of feeds: improves digestion and palatability of feeds, digestibility of feeds is increased significantly to 95%. As a result, the gain of animals increases, feed costs reduce, the loss of youth reduces due to reduction of bacteria in grain.

Technical specifications:

Productivity during soybean processing, in kg / h 250

Performance during processing cereals and peas, kg / h 210

Power consumption, kW/h 37

Length, mm 2000

Width, mm 1970

Height, mm 1650

Weight, kg 1000

Warranty period of wearing parts, hours 400

Warranty period, months 12

------------------------------------

Extruder grain and soy 500 kg / h

------------------------------------

This equipment is intended for production of extruded combi-feeds for cattle, pigs and poultry, and can also be used for production of full-fat soybean meal with high digestibility due to complex structural changes that take place in the grain during extrusion and purification from pathogenic organisms exposed to 20-30 atm. and temperature - 120-180 ° C.

This extruder can process grain and corn cereal, wheat, barley, rye, peas, soybeans, sunflowers and others. Application of extruder improves significantly food quality of feeds: improves digestion and palatability of feeds, digestibility of feeds is increased significantly to 95%. As a result, the gain of animals increases, feed costs reduce, the loss of youth reduces due to reduction of bacteria in grain.

Technical specifications:

Productivity during soybean processing, in kg / h 500

Performance during processing cereals and peas, kg / h 310

Power consumption, kW/h 55

Length, mm 2300

Width, mm 2100

Height, mm 1700

Weight, kg 1400

Warranty period of wearing parts, hours 400

Warranty period, months 12

------------------------------------

Extruder grain and soy 1000 kg / h

------------------------------------

Extruder is designed for production dry fodder for cattle, pigs, domestic animals and poultry as well as for production extruded semi-fat soybean and sunflower meal with high digestibility and disinfection against harmful micro-organisms and substances.

The extruder allows to process grain and cereals of wheat, rye, corn, barley, peas, beans, lupins, soya beans, to stabilize rice bran

Application of this extruder allows to:

- feed production of high quality

- save up to 40% of the grain in feeding animals

- efficient use of the available raw materials

- used to control the quality of feed

- cleaned substandard raw materials from microorganisms

- save up to 30% of the energy in the preparation of soybean, rapeseed and sunflower for oil extraction

- reduce the level of urease in extruded soybeans to pH 0.1-0.2

How it works:

The grain using the screw feeder is fed from the hopper into the working body of the extruder. The raw is fed from the hopper via the feeder into the feeding chute of the working body. The raw material feeding can be adjusted by changing the screw turnovers in the feeder of the extruder. There is magnet-catcher pf metal particles inside the chute. Inside the working body the extrudant is squeezed through the forming die.

Technical specifications:

Productivity in processing of cereals and peas, up to kg / hour 700

Productivity during soybean processing, up to kg / hour 1000

Productivity in the processing of animal wastes up to kg / hour 500

Power consumption, kW/hour 92,5

Length, mm 2500

Width (with cutter), mm 2600

Height, mm 2000

Weight, mm 2000

Warranty period, months 12

------------------------------------

Extruder grain and soy 1500 kg / h

------------------------------------

Application:

This model of extruder is used for semi-wet feeds for farm animals, pets, cats, dogs, fish, poultry, shellfish and shrimp. The resulting feed has a high digestibility and purified from pathogenic organisms. It is possible to add protein and mineral supplements into the raw materials of extrusion. The extruder is also used for soybean processing to obtain textured protein. The raw material for processing in this extruder can be: grain and cereal of corn, wheat, rye, barley, pea, rape, soybean, sunflower, and also it is possible to use mixtures of various components, and soy flour.

Advantages:

production of high quality feeds;

possibility of producing feed with protein supplements;

possibility to produce floating, sinking and soaring feeds;

granules resistant to transportation;

usage of various food waste for cooking raw mixes;

reduction of feed consumption due to the high percentage of digestibility.

Raw materials

wheat, neigh, maize, barley, peas, beans, soybeans, rape and sunflower, as well as complex mineral supplements and soy flour

Technical specifications:

Capacity for soybean processing, kg / hour: 1500

Capacity for feed processing, kg/hour: 500

Power, kW: 97

Steam consumption per 1 kg of feed, kg: 100

Length, mm: 2400

Width, mm: 2400

Height, mm: 2850

Weight, kg: 2400

------------------------------------

The extruder is driven by the PTO to 250 kg / h

------------------------------------

This equipment is intended for production of extruded combi-feeds for cattle, pigs and poultry with high digestibility due to complex structural changes that take place in the grain during extrusion and purification from pathogenic organisms exposed to 20-30 atm. and temperature - 120-180 ° C.

The drive of the extruder is the power takeoff shaft (PTO) of the tractor with safety clutch. The extruder is suitable for use directly in the field or in places with low-power electric networks.

This extruder can process grain and cereal of corn, wheat, barley, rye, peas, soybeans, sunflowers and others.

Application of extruder improves significantly food quality of feeds: improves digestion and palatability of feeds, digestibility of feeds is increased significantly to 95%. As a result, the gain of animals increases, feed costs reduce, the loss of youth reduces due to reduction of bacteria in grain.

Technical specifications:

Performance (soybean), kg/h 250

Tractor PTO rotation frequency, rev/min 540

Rated torque, Nm 620

Maximal torque, Nm 1050

Parameters of PTO (zxdxD), mm 6х29х35

Tractor drive power , kW 36

Power supply parameters 220 V, 1 phase/50Hz, 4 А

Dimensions LхWхH, mm 1710х910х1610

Weight, kg 420

------------------------------------

For the production of corn sticks

It serves for the production of cereal sticks of various shapes and length from various types of cereals separately or in mixtures, porridges and soups of rapid (moment) preparation..

Howitworks: cereals is fed from the hopper by screw feeder to the working body of the extruder, where it is melted under the exposure of high temperatures (120-140 ° C) and friction. Then, this mass moves out by thescrew to the exit from the head of the extruder through a matrix with a hole of a certain size (the thickness of the stick depends on the hole size). The molten mass expose outside at the moment of its appearance due to the pressure difference in the extruder head and the atmosphere pressure, quick evaporation of moisture. The product increases in volume by 3-4 times in an explosion. Then, the necessary length of the sticks is generated with the help of an edging device.

Technical characteristics:

Grain extruder W-40 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-75 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-95 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-150 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-170 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-200 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-350 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

Grain extruder W-450 for grain processing extruded feed.

We can say that the extruder performs half of the animal’s stomach work, as in the processing there are several changings in grain: fiber digestibility increases; protein denaturation promotes absorption; starch gelatinization and gelation; under high pressure - 20-30 atm. and temperature - 120-180 ° C the dangerous microflora (bacteria, mold, fungi) dies. As the result of these changes the feed digestion and palatability of feed increase, the feed digestibility significantly increases up to 95%. It results the animal gain, reduces the feed cost, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:

This model of extruder is capable to process the raw material with high content of protein, i.e. to use the meat and fish processing wastes in the combi-feed composition.

The extruder is capable of processing cereal grains and corn, wheat, barley, rye, peas. Application of extruder significantly improves nutritional quality of feeds: improves digestion and palatability of feeds, digestibility of feed significantly increases up to 95%. It increases the gain of animals, reduces feed costs, reduces the loss of cubs due to the reduction of bacteria in the grain.

Technical characteristics:
